Index
|
| Page No. |
Subject |
| 1 |
1 Sheet Metal Working |
| 1 |
Hand Tools |
| 6 |
Template Making |
| 7 |
Sheet Metal Developments |
| 10 |
2 Milling Setting Operating |
| 10 |
Gear Tooth Vernier |
| 11 |
Gauging |
| 13 |
Types of Cutting Tools |
| 14 |
Lubricants |
| 15 |
Vices & Attachments |
| 17 |
Speeds & feeds |
| 21 |
Gang Milling |
| 22 |
Tolerance, Fits & Limits |
| 24 |
Chucks & Arbors |
| 27 |
3 General Fitting |
| 27 |
Screw threads |
| 30 |
Bending Allowance |
| 33 |
Removing Studs & Taps |
| 35 |
Welded Patches |
| 35 |
4 Electric Welding |
| 35 |
Carbon Arc & Inert Gas welding |
| 36 |
Flame Cutting |
| 37 |
Welding Joints |
| 38 |
Thermal Expansion & Contraction Allowance |
| 39 |
Fillet weld |
| 40 |
Weld Tests |
| 41 |
5 Centre Lathe No 2 |
| 41 |
Single Point Tools |
| 42 |
Boring Tools |
| 43 |
Taper Turning |
| 43 |
Screw Cutting |
| 46 |
Multi-Start Screw Threads |
| 47 |
Surface Texture |
| 48 |
Tunsten Carbide, Ceramic & Diamond Tools |
| 49 |
6 Capstan setter Operator No 3 |
| 49 |
Capstan & Turret Lathes |
| 49 |
Single Point Lathe Tools |
| 51 |
Tapping Drills |
| 52 |
Dies & Reaming |
| 53 |
7 Precision Grinding |
| 53 |
Churchill OHX Gring M/C With Air Bearings |
| 55 |
Measurement of Surface Finish |
| 56 |
Sine Bar |
| 57 |
Visit to Kaye Alloys |
| 59 |
8 General Fitting, Shaping Machine |
| 59 |
Fastening & Locking Devices |
| 61 |
Brazing |
| 61 |
Bearings |
| 63 |
Shaping Machine |
| 64 |
19 Centre Lathes |
| 64 |
Centre Lathe Headstock & Feedbox Arrangement |
| 67 |
Centre Lathe Tailstock & Feed Shaft Clutch Mechanism |
| 68 |
20 Capstan Setter Operator No 2 |
| 68 |
Herbert Air/Electric Operated Chucks |
| 70 |
Herbert 2D Capstan Lathe with EMI-MEC Automation System |
| 72 |
British Standard Surface Finish Symbols |
| 73 |
21 General Fitting |
| 73 |
Micrometer |
| 75 |
Gears Involute & Cycloidal |
| 76 |
Gears Spur, Worm & Wheel |
| 77 |
Gears Rack & Pinion, Bevel, Helical & Spiral |
| 78 |
22 Electric Welding |
| 79 |
Electrodes |
| 80 |
Metals - Cast Iron, Aluminium, Bronze |
| 81 |
BS 499 Weld Symbols |
| 81 |
23 Instrument Maintenance |
| 81 |
Sinusoidal Waveform |
| 83 |
Direct Current Motor |
| 85 |
Alternating Current Circuit |
| 87 |
Practical AC Circuit |
| 88 |
Thermometer |
| 90 |
24 Milling Setter Operator No 2 |
| 90 |
Vernier Sliding Calliper |
| 91 |
Dividing Head Indexing |
| 91 |
Plain & Simple Indexing |
| 93 |
Compound Indexing |
| 94 |
Differential Indexing |
| 97 |
Workshop Experience Objectives for Trainee Draughtsman |
